Welcome to Synergy Circuits

Synergy Circuits is an ISO certified company that offers comprehensive Engineering-CAD-Manufacturing printed circuit board solutions. Our strength in PCB layout for cost effective fabrication, and assembly has been the core value of our service.
We specialize in end-to-end PCB development, as well as PCB cost optimization with our strong knowledge in multi-regional Design For Manufacturing capabilities and cost drivers. We also have customers provide us cost reduction targets on existing products in production, and we can evaluate the PCB design for cost optimization.

Design Capabilities:

  • 30+ years of experience in designing Commercial board designs and Test board designs for Analog, High Speed Digital, Mixed Signal, RF signals up to 40 GHz.
  • Various engagements in 5G network PCB development.  Test boards for BGAs designed for 5G networks.   RF products related to broadcasting for 5G network requirements.  Characterization PCBs for bench testing environments for 5G Applications.
  • Highly experienced in designing test boards for leading ATE test system Vendor’s Tester Platforms.
  • Experience in designs requiring leading interface technologies such as USB 2.0, USB 3.0, HDMI, UART, I2C,  PCI, PCIe, SATA, SAS, DDR 2, DDR3, Ethernet PHY Interface/Serdes, and more.
  • Experience in Selecting optimum PCB materials when required including high frequency laminates (Rogers/Tachyon), high temp requirements (Arlon85n), and RF requirements (Rogers/MW2000/Tachyon100G).
  • Stack up optimization for high layer count PCBs (60 layers) and experience in handling Multiple Impedance control (50/90/100 ohm) on the same board.
  • Experienced in Design of ELIC boards (Every Layer Interconnect/HDI laser/filled stacked-vias) for Smartphone or other Mobile PCB applications.
  • Experience with fine pitch BGA (0.3mm) and multiple high pin count FCBGAs.
  • Specialized in commercial high speed and high layer count designs with multiple FBGAs including Processors, Memory units, High speed interfacing units, Controllers, Power modules/heat sinks and multiple IO interface ports/connectors.
  • We have been providing services for various that include Consumer Electronics, Semiconductor Industries, Telecommunications, Medical, Aero-space and Military applications.

Providing complete Hardware solution







  • High Speed Digital PCB designs
  • High Frequency RF/ Microwave PCB
  • Fine Pitch/Multi-DUT ATE Final Test boards
  • Multi-DUT Wafer Sort Probe boards
  • Template (Advantest T2K/93K/6600/legacy Testers)
  • Template (Terradyne I-Flex/U-Flex/Ultra-Flex/J750/ETS testers)
  • Motherboard-to-Interchangeable Daughter board Testing Concepts
  • PCB designed into Medical devices
  • HDI designs for fine pitch BGA circuitry
  • Up to 64 layers PCB construcion
  • Up to 60Gbps transmission lines
  • Detailed Documentation of Fabrication-Assembly drawings
  • Signal and power integrity simulation for PCB.
  • Layer stack up optimization.
  • S-parameter measurements and channel optimization.
  • PCB channel pre-simulation and post-simulation for 40G+ frequencies.
  • Crosstalk and TDR simulations and optimization.
  • PCB decap requirements and optimization.
  • PCB power supply impedance profile and loop inductance measurements.
  • 3D/2.5D model extraction and electrical simulations

Certified to ISO 9001:2015

Certificate No. 0925Q01919
